Description
Our complete set of screws & pins for the U. S. Model 1803 Harper’s Ferry Rifle are made of unplated steel, with slotted heads. These are becoming scarce.Our set includes:
- 2 BOLT-L-1803 lock bolt, 8-32, 3/8″ head, for mounting the lock, plus
- 1 BOLT-T-8-OL tang bolt, 8-32, countersink oval head, plus
- 2 SCREW-10x1V wood screws, 10 x 1″, for mounting the buttplate, plus
- 2 SCREW-6×5/8 wood screws, 6 x 5/8″, for mounting the trigger plate, plus
- 3 SCREW-8×5/8 wood screws, 8 x 5/8″, for mounting the patchbox head, plus
- 4 PIN-3/32 steel dowel pins, 3/32″ diameter, for barrel lugs and rod pipes
We recommend that you also order: DRILL-3/32″ to install the steel dowel pins, TAP-8-32-T taper tap, 8-32, to install the lock and tang bolt and other drill bits as needed for tap drills and clearance drills, for the several bolts and screws.
